| Valve type | EFC | EDD | EBC |
| Common design features High flow water |  |  |  |
| Main applications | Feed water control | Recirculation high pressure drop | Inflamable fluid control Fluid control valve |
| Body style | Angle configuration Cast Globe for low flow | Angle configuration Cast Globe for low flow | Globe |
| Body material | Forged CrMo-low alloy or carbon steel | Forged CrMo-low alloy or carbon steel | Cast |
| Max pressure class | ANSI # 2500 | ANSI # 2500 | ANSI 150 -2500 # |
| Max body size | 300mm (12 inch ) | 100 mm ( 4 inch ) | DN 300 |
| Max capacity, Kv (Cv) | 4000 (4720) | 80 ( 95) | 800 ( 940) |
| Leakage class | V | V | IV-V |
| Plug design available | Contour Cage | Labyrinth Multipatch | Single stage contour, single stage Cage Two stage contour+cage Balanced Tight |
| Special design features | Suitable for feed water Body remains intact from erosion . Long Life | Multipath reduction | Standardized cast body with flanged Butt weld design Also available for steam service Available for other fluids as control valve |
